AI-64 CPSW and hardware traffic queues

General Discussion
1

Hello,

I am trying to enable hardware traffic queues in the AI-64 EMAC/CPSW.

I perform:

sudo ifconfig eth0 down
sudo ethtool -L eth0 tx 2

but get an Oops:

Message from syslogd@BeagleBone at Nov 15 07:57:12 ...
 kernel:[  456.241636] Internal error: Oops: 96000004 [#1] SMP

Message from syslogd@BeagleBone at Nov 15 07:57:12 ...
 kernel:[  456.511468] Code: f8408c61 d2800013 eb03003f 54000100 (a9428820)
Segmentation fault

I’m using the latest 11.3 bbai64 image.

Do the latest images include TI patches for CPSW for TDA4?

Thanks!
Kieran.

2

update - it works with the bbai64-debian-11.5-minimal-arm64-2022-11-01-4gb.img.xz from the monthly snapshots post, just not from the 11.3 image on the main beagleboard.org webpage, sorry for the noise.

3

Glad it works on a newer image… The “new” site has that file going forward, eventually the old site will be replaced:

Screenshot

Regards,
