[beagle-alpha] Wilink8 features to explore: Wake on WLANand802.11s mesh

[Gi_Soo_Kim]

Hi!

I successfully run MESH+STA or MESH+AP. However, I liked to run these mode on boot.

So I found website in order to make that happen.

Here is what I did

1. move script file on /etc/init.d/script_name(mesh_start.sh and ap_start.sh)

2. update-rc.d <script_name> defaults

So for the AP, i used for ap_start.sh. For Mesh, i used mesh_start.sh

After boot up ap_start.sh works fine but mesh_start.sh does not work perfect

[ 56.906613] wlcore: down
[ 56.996344] IPv6: ADDRCONF(NETDEV_UP): mesh0: link is not ready
[ 57.026577] IPv6: ADDRCONF(NETDEV_CHANGE): mesh0: link becomes ready

After that it supposed to be create mesh network but it does not.

I assumed in mesh_start.sh

*wpa_supplicant -e/usr/share/wl18xx/entropy.bin *
-imesh0 -Dnl80211 -c mesh_supplicant.conf &

This two lines does not run properly

In order to run wpa_supplicant, am I have to initialize wpa_supplicant first because I do not have /etc/init.d/wpa_supplicant?

If you say, do you know how to initialize wpa_supplicant?

I am using

Linux version - 4.4.19-gdb0b54cdad

Board - BeagleBone Green Wireless

mesh_start.sh

#!/bin/sh

#!/usr/sbin/wpa_supplicant

sleep 15

MESH=mesh0

add Mesh interface, if not present

if [ ! -d /sys/class/net/$MESH ]

then

echo “adding $MESH interface”

iw phy ls /sys/class/ieee80211/ interface add $MESH type mp

fi

if ps -w | grep -v grep | grep wpa_supplicant | grep mesh0 > /dev/null

then

echo “wpa_supplicant is already running(Mesh)”

exit 0

fi

sleep 15

wpa_supplicant -e/usr/share/wl18xx/entropy.bin \

-imesh0 -Dnl80211 -c wpa_supplicant.conf &

sleep 1

iw phy phy0 set rts 0

ifconfig mesh0 10.20.30.41 netmask 255.255.255.0

iptables -t nat -A POSTROUTING -o mesh0 -j MASQUERADE

udhcpd /usr/share/wl18xx/udhcpd_mesh.conf

Thank you!

[jkridner]

Hi!

I successfully run MESH+STA or MESH+AP. However, I liked to run these mode on boot.

Can you describe the process you followed, step by step including the starting image, to get this working not-on-boot? Going from there to making it work on boot should be relatively straight-forward.

So I found website in order to make that happen.

What website?

Here is what I did

1. move script file on /etc/init.d/script_name(mesh_start.sh and ap_start.sh)

Move it where?

2. update-rc.d <script_name> defaults

So for the AP, i used for ap_start.sh. For Mesh, i used mesh_start.sh

After boot up ap_start.sh works fine but mesh_start.sh does not work perfect

[ 56.906613] wlcore: down
[ 56.996344] IPv6: ADDRCONF(NETDEV_UP): mesh0: link is not ready
[ 57.026577] IPv6: ADDRCONF(NETDEV_CHANGE): mesh0: link becomes ready

After that it supposed to be create mesh network but it does not.

No extra log information? How do you know about it working or not working?

I assumed in mesh_start.sh

*wpa_supplicant -e/usr/share/wl18xx/entropy.bin *
-imesh0 -Dnl80211 -c mesh_supplicant.conf &

What is the contents of mesh_supplicant.conf? Do you need to point to its full path?

This two lines does not run properly

In order to run wpa_supplicant, am I have to initialize wpa_supplicant first because I do not have /etc/init.d/wpa_supplicant?

If you say, do you know how to initialize wpa_supplicant?

I am using

Linux version - 4.4.19-gdb0b54cdad

Board - BeagleBone Green Wireless

mesh_start.sh

#!/bin/sh

#!/usr/sbin/wpa_supplicant

Is this really meant to be a “shebang” line? In a script, not being the first line, it’ll be ignored, which makes some sense because it wouldn’t interpret anything properly. I just don’t know why this is here.

sleep 15

MESH=mesh0

add Mesh interface, if not present

if [ ! -d /sys/class/net/$MESH ]

then

echo “adding $MESH interface”

iw phy ls /sys/class/ieee80211/ interface add $MESH type mp

fi

if ps -w | grep -v grep | grep wpa_supplicant | grep mesh0 > /dev/null

then

echo “wpa_supplicant is already running(Mesh)”

exit 0

fi

sleep 15

wpa_supplicant -e/usr/share/wl18xx/entropy.bin \

-imesh0 -Dnl80211 -c wpa_supplicant.conf &

sleep 1

iw phy phy0 set rts 0

If this is waiting for an interface to become available from wpa_supplicant, ‘sleep 1’ might not be enough. Perhaps a set of udev rules would make more sense?

ifconfig mesh0 10.20.30.41 netmask 255.255.255.0

iptables -t nat -A POSTROUTING -o mesh0 -j MASQUERADE

udhcpd /usr/share/wl18xx/udhcpd_mesh.conf

Another configuration file without source.
